Atomos Sumo PRO-19 4K Production Monitor
Product Code: B158115Q
Share this item:
The Atomos Sumo PRO-19 4K Production Monitor is a 4K HDR DCI-P3 monitor-recorder-switcher with ProRes, ProRes RAW and DNx recording, built for multi-camera on-set monitoring, ISO capture and live production workflows.
Pre-order today for first available UK stock. First deliveries from late May.
Earn 2910 Park Points
Atomos Sumo PRO-19 4K Production Monitor Summary
The Atomos Sumo PRO-19 is a 19-inch 4K HDR production monitor that combines monitoring, recording and switching in a single unit. It sits at the centre of on-set workflows, providing a large, colour-accurate display alongside multi-camera input handling and ISO recording.
It supports recording in Apple ProRes, ProRes RAW and Avid DNx formats to CFexpress or external USB-C storage, while handling up to four camera inputs simultaneously with a fifth program output. The 1200-nit touchscreen display covers 99% DCI-P3 and 100% Rec.709, supporting accurate HDR and SDR monitoring.
With 12G-SDI and HDMI connectivity, integrated Wi-Fi, Ethernet and AirGlu timecode sync, it supports both traditional broadcast setups and modern cloud-based workflows. This makes it suitable for directors, technical crews and production teams working across multi-camera shoots, live events and video village environments.
Atomos Sumo PRO-19 Key Features
- 19-inch 4K HDR touchscreen display with 1200 nits brightness and DCI-P3 colour coverage
- Records ProRes, ProRes RAW and Avid DNx formats to CFexpress or USB-C storage
- Supports up to four ISO recordings with an additional program output
- Quad-view multi-camera monitoring with selectable full screen or split layouts
- Includes AirGlu RF and Bluetooth timecode synchronisation
- Provides 12G-SDI, 3G-SDI and HDMI input and output connections
- Offers EL Zone false colour, waveform, vectorscope and focus assist tools
- Enables direct upload via Wi-Fi and Ethernet to cloud platforms including frame.io
Atomos Sumo PRO-19 4K Production Monitor In More Detail
19-inch 4K HDR display
The Sumo PRO-19 features a 19-inch touchscreen production monitor with a resolution of 3840 x 2160 and a peak brightness of 1200 nits. It covers 100% Rec.709, 99% DCI-P3 and 99% NTSC, supporting HDR monitoring and log workflows used in professional video production.
The display supports log to LUT viewing with compatibility for 3D LUTs and .cube files. This allows crews to monitor a graded image while recording log footage, maintaining consistency between capture and post-production.
Multi-camera monitoring and switching
The unit accepts up to four video inputs simultaneously and provides quad-view monitoring or single input full screen. Each feed can be monitored independently or within a multi-camera layout, supporting live production and broadcast environments.
A fifth program output can be generated, allowing switching between inputs for live output or recording. The selected program feed is available via SDI or HDMI output for downstream devices.
Recording formats
Recording supports Apple ProRes, ProRes RAW and Avid DNx formats, with up to 12-bit capture depending on source. Media options include CFexpress Type B cards or external USB-C storage devices.
The system records up to four ISO feeds while simultaneously capturing a program output, supporting flexible editing and post-production workflows.
Professional Connectivity and I/O
The Sumo PRO-19 includes 2 x 12G-SDI inputs, 2 x 3G-SDI inputs, 12G-SDI output and HDMI input and output. These connections support up to 4Kp60 signals, with loop-through and playback output options available.
Audio is handled via XLR inputs with selectable 48V phantom power, alongside XLR outputs for monitoring. A sync input allows reference locking for playback workflows, and Gigabit Ethernet supports network-based production setups.
Timecode and synchronisation
AirGlu technology provides wireless timecode sync using RF and Bluetooth. This allows cameras, audio recorders and monitors to maintain aligned timecode without physical connections.
This supports multi-camera productions where consistent timing across devices is required.
Monitoring tools
A full suite of monitoring tools is included, such as EL Zone false colour, waveform, vectorscope, RGB parade, zebras and focus peaking. These tools support exposure control, colour accuracy and focus confirmation directly on the monitor.
Additional tools include frame guides, grid overlays and anamorphic desqueeze, supporting a wide range of shooting formats and framing requirements.
Workflow integration
Integrated Wi-Fi and Ethernet support direct upload to cloud services including ATOMOSphere, Frame.io and Dropbox. This enables camera-to-cloud workflows for remote review and collaboration.
Playback functionality allows immediate review of recorded footage on set, supporting decision-making without moving media to external systems.
Frequently Asked Questions
Can the display be calibrated?
Yes, the production monitor supports calibration using compatible Calibrite devices via a PC or Mac connection.
Does the Sumo PRO-19 support LUTs?
Yes, it supports real-time LUT preview and allows custom .cube LUTs to be loaded from CFexpress or USB-C storage.
How many camera feeds can be recorded?
It can record up to four ISO camera feeds alongside a fifth program output.
What viewing layouts are available?
It supports full screen viewing for a single input or quad-view multi-camera monitoring.
What are the front function buttons used for?
Up to six functions can be assigned for quick access to monitoring tools, LUTs and playback features.
Which signal is output via SDI or HDMI?
The selected program output is routed to the SDI and HDMI outputs.
Atomos Sumo PRO-19 Specifications
|
Screen Size |
19-inch |
|
Resolution |
3840 x 2160 4K UHD |
|
Brightness |
1200 nits |
|
Colour Coverage |
100% Rec.709, 99% DCI-P3, 99% NTSC, 87% BT.2020 |
|
Recording Formats |
ProRes, ProRes RAW, Avid DNx |
|
Bit Depth |
Up to 12-bit |
|
Recording Media |
CFexpress Type B, USB-C external storage |
|
Video Inputs |
2 x 12G-SDI, 2 x 3G-SDI, HDMI |
|
Video Outputs |
12G-SDI, HDMI |
|
Audio Inputs |
XLR with 48V phantom power |
|
Audio Outputs |
XLR |
|
Timecode |
AirGlu RF and Bluetooth |
|
Network |
Gigabit Ethernet, Wi-Fi |
|
Max Resolution Support |
Up to 4Kp60 |
What’s in the Box
- Sumo PRO-19 monitor-recorder-switcher
- 2x Wi-Fi antennas
- 5x antenna tips
- AirGlu antenna
- 3x antenna caps
- Desktop feet and screws
- Battery mount and screws
- XLR 4 power supply
- International IEC power cables
- Screen cloth
- HEX key
- Quick Start Guide
